Cordless circular saw C3605DA

36 V Brushless 125 mm circular saw with 47 mm cutting depth

  • Equipped with innovative deep cut technology for higher cutting depth with standard saw blade
  • Optimal saw blade visibility from both sides guarantees high-precision cuts
  • Fast stopping brake for high user safety
  • Very compact and lightweight for maximum flexibility
  • Equipped spindle lock for fast and easy blade change
  • Automatic Power and Silent Function - The Silent function significantly reduces saw noise and the saw automatically switches to Power mode when under load
  • Kickback Protection System: detects a sudden drop in engine speed and stops the engine quickly to reduce reaction force
  • Selective LED mode, three modes: ON, LOCK and OFF.
  • Chip blowing function for always free cutting
  • With soft start function
  • MULTI VOLT battery technology: AC power, DC freedom
  • Brushless motor for high power, less wear and a long service life

For price information, please visit your country’s website or contact your local dealer.

Find a dealer
More information
Articlenumber
C3605DA
Battery voltage
36 V
Blade diameter
125 mm
Bore size
20 mm
Max. cutting depth (0°)
47 mm
Max. cutting depth (45°)
30 mm
Maximum bevel angle
45 °
Undercut angle
None
Weight (without battery pack)
2 kg
Weight (with battery pack)
2.7 kg
Tool length
277 mm
Tool width
176 mm
Tool height
236 mm
Dust box attachment
None
Material: gear cover
Aluminum Die Cast
Brake
Yes
Kick back protection
Yes
Soft start
Yes
Chip blower
Yes
LED light
Yes
Brushless
Yes
No load speed
5000/2,600 /min
ETIM Class
EC001380
The actual product may differ from the picture. Please note the product description, technical data and scope of delivery.
  • Stackable System Case 4
No accessories available
